Euchner N01K550-M (ORDER NO. 084904) Precision Single Limit Switch N01, Ball Plunger

Xiamen ZhiCheng Automation Technology Co., Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Euchner N01K550-M (ORDER NO. 084904) Precision Single Limit Switch N01, Ball Plunger

Brand Name : Euchner

Model Number : N01K550-M

Certification : UL,CCC,etc.

Place of Origin : Germany

MOQ : 1

Price : variable

Payment Terms : T/T

Supply Ability : 100PCS/MONTHS

Delivery Time : Negotiate

Packaging Details : Carton

Manufacturer : Euchner

Product NO. : N01K550-M

Product type : Precision single limit switch

Warranty : 1 Year

Moq : 1 Set

Contact Now

Euchner N01K550-M (ORDER NO. 084904) Precision single limit switch N01, ball plunger

Specification


Part Number: N01K550-M
Manufacturer: Euchner
Condition : Brand New
Warranty : 12 months
Product Type Precision single limit switch

Euchner N01K550-M (ORDER NO. 084904) Precision Single Limit Switch N01, Ball Plunger

Euchner N01K550-M (ORDER NO. 084904) Precision Single Limit Switch N01, Ball Plunger

Electrical connection values

Connection cross section 0.14 ... 1 mm²
Rated insulation voltage Ui 250 V
Rated impulse withstand voltage Uimp 2.5 kV
Utilization category
DC-13 2 A 24 V
AC-15 2 A 230 V
Short circuit protection according to IEC 60269-1 6A gG
Switching current
min. at DC 24V 10 mA
thermal rated current Ith 6 A

Mechanical values and environment

Approach speed 0.01 ... 8 m/min
Connection type
1 x M12 x 1.5
Number of door position NC contacts 1 Changeover contact
Number of door position NO contacts 1
Actuating element
Steel ball D ball = 4 mm Ball plunger
Actuating force 15 ... 20 N
Installation orientation any
Mechanical life 10 x 10⁶
Switching principle Changeover contact with snap-action function
Degree of protection IP67
Ambient temperature -5 ... +80 °C
Material
Housing Anodized die-cast alloy
Contact Silver alloy, gold flashed
